SLAB / FOUNDATIONS
– ‘H1’ Class Engineered designed waffle pod slab (excluding alfresco and porch) with pad footings for piers.
– Includes SL82 fabric mesh, N12 bars & 3-L12 trench mesh with 385mm overall slab height.
SITE EXCAVATION
– Excavation and soil removal with an allowance for 300mm fill, 300 mm fall on building perimeter with a balance cut and fill.
COUNCIL & OH&S REQUIREMENTS
– OH&S requirements and certifications
– Crossover Protection & Silt Sediment control where applicable
– Temporary Site fencing & rubbish cage
– Warranty Insurance
– Occupancy Certificate
CONNECTIONS
– Includes connection of water, gas, electricity (single phase), sewer, stormwater points within the allotment
– Includes conduit for fibre optic run-in from pit to side of dwelling (Single Storey)
– Does not include electricity and telephone connection cost, or account opening fees and usage charges.
– 1 x external water tap to rear in addition to mains metered water tap
WARRANTIES & GUARANTEES
– 7 year structural guarantee
– All statutory warranties, insurances and guarantees
– 6 month maintenance period
– Independent inspections by registered building surveyor
– Termite protection (If required)
FRAME
– MGP 10 pine 90mm wall frames and engineered designed roof trusses
EXTERNAL CLADDING (SINGLE STOREY)
– Bricks hand selected by our team of expert interior designers (Refer to chosen colour scheme)
– Brick infills above windows to front Elevation (design specific)
– Feature render to facade (One colour, product specific)
– 4.5mm fibre cement sheet infills above windows to side and rear elevations & garage opening (refer to working drawings)
– Natural colour round rolled mortar joints to brickwork
– Autoclaved aerated concrete panels to whole house with render finish. (One colour – AAC design specific)
EXTERNAL CLADDING (DOUBLE STOREY)
– ACC Autoclaved aerated concrete panels (AAC) with render finish
– Feature render to façade (Two colour – product specific, refer to chosen colour scheme))
ROOFING MATERIAL
– Roof made from Colorbond® steel, or concrete roof tiles, colour hand selected by our team of expert interior designers (Single Storey)
– 22.5 degree roof pitch
– Roof made from Colorbond® steel (Double Storey)
GUTTER / FASCIA / DOWNPIPES
– Colorbond® gutter, fascia & downpipes
WINDOWS
– Powder coated aluminium feature windows to front elevation (facade specific)
– Powder coated aluminium sliding windows & sliding doors to remainder of home (design specific)
– Keyed window locks to all openable windows
FRONT DOOR
– Feature painted front entry door.
– Round keyed Terrace set to front entry door
GARAGE
– Colorbond® sectional panel (slimline) garage door with handle to lift up (Single Storey)
– Colorbond sectional panel (flat line) garage door with handle to lift up (Double Storey)
– Concrete floor line
– Painted cement sheet infill above garage door opening (refer to working drawings)
– Weatherproof hinged flush panel rear access door with aluminium door frame (If applicable)
EXTERNAL PAINTWORK
– Low sheen acrylic paint to all external surfaces
– Semi-Gloss enamel paint to front entry door
– Flat matt paint to ceiling of alfresco, porch, and eaves (If Applicable – Single Storey)
– Flatt matt paint to ceiling of alfresco, porch, balcony and eaves (If Applicable – Double Storey)
